Product Details
Tray
Stainless steel perforated tray with intervals of ½
Door
Heavy duty toughened double glass door installed with imported hinges and lock for easy operation.
Construction
Double wall inner tank and outer body is dynamically designed. The Equipment interior is constructed with stainless steel 304 grade finish-4 and exterior is constructed with powder coated GI sheet/ stainless steel 304 grade finish-4.
Optional Backup System
Equipment is installed with PLC based auto change over backup system for Refrigeration system and Steam Generator system.
PLC based control system
- Controlling system- PLC
- PC Communication via Ethernet
- PLC Based Safety cut off
- Rotronic make 4 to 20 mA sensors
- 4.3” HMI with TFT LCD Colour touch screen
- PLC based auto tune facility
- User based Alphanumeric password protection through HMI
Technical Specification
| Specification | Temperature | Humidity |
| Range | 20°C to 60°C | 40%RH to 85%RH |
| Accuracy | +/- 0.2°C | +/- 2.0% |
| Uniformity | +/- 1.0°C | Uniformity +/- 3.0% |
Technical Specification
| Models | Capacity | Internal size in MM | External size in MM | Tray Qty | Tray size in MM | Total Load |
| AD/SC-15 | 150 | 500Wx400Dx750H | 625Wx1100Dx1650H | 2 | 425Wx395Dx30H | 3KW |
| AD/SC-25 | 250 | 600Wx400Dx1050H | 725Wx1100Dx1650H | 2 | 525Wx395Dx30H | 3KW |
| AD/SC-40 | 400 | 700Wx500Dx1150H | 825Wx1200Dx1750H | 3 | 625Wx495Dx30H | 3.5KW |
| AD/SC-50 | 500 | 700Wx600Dx1200H | 825Wx1300Dx1800H | 3 | 625Wx595Dx30H | 3.5KW |
| AD/SC-60 | 600 | 700Wx600Dx1450H | 825Wx1300Dx2050H | 3 | 625Wx595Dx30H | 3.5KW |
| AD/SC-80 | 800 | 700Wx800Dx1450H | 825Wx1500Dx2050H | 4 | 625Wx795Dx30H | 3.5KW |
| AD/SC-100 | 1000 | 800Wx800Dx2050H | 925Wx1500Dx2200H | 4 | 725Wx795Dx30H | 3.5KW |
